| Datasheet: | Download |
|---|---|
| Rotational Life: | 15,000 cycles |
| Contact Resistance: | 3Ω max. |
| Insulation Resistance: | 100MΩ minimum at 500VDC |
| Resistance Range: | 500 Ω to 2 M Ω (B) 1 k Ω to 2 M Ω (A,C) |
| Adjustment Travel: | 290°±10° |
| Operating Temperature Range: | -10℃ to +85℃ |
| Electrical Angle: | 245°±10° |
| Mechanical Angle: | 290°±10° |
| Lead Free: | Yes |
| RoHS Compliant: | Yes |
| Power Rating: | 0.25 W (B) at +40°C 0.125 W (A,C) at +40°C 0 W at +85°C |
| Tolerance: | ±20 % Standard |
| Rotational Angle: | 290°±10° |
| Dimension: | 20mm Diameter |
| Element: | Carbon |
RV20N
- 20mm diameter, single-turn industrial panel controls
- Carbon film element
- Single unit, single shaft
- Linear or audio tapers
- Plastic M9xP0.75 bushing
- Plastic 6mm diameter shafts in slot or flat end styles
- Standard 15mm or 20mm shaft length
- Panel mounting styles only
- Right angle lug terminals
- Meets UL 94HB flammability requirements for plastic materials
APPLICATIONS
